Note:
B+ STUD ON SOLENOID 22mm OAL
TOP RH MTG. EAR 8mm x 1.25
BOTTOM RH MTG. EAR 9mm UN THREADED
TOP RH MTG. HOLE LOCATING PIN 8mm OD
Applications:
Fiat Car 500L L4 1.4L 1368cc 83cid 2014-2016
Fiat Truck 500X L4 1.4L 1368cc 83cid 2016
Jeep Truck Renegade L4 1.4L 1368cc 83cid 2015-2016
Specifications:
Description: Starter
Voltage: 12
Power: 1kW / 1.34HP
Condition: New
Rotation: CW
Starter Type: PMGR
Number of Teeth: 10
Gear OD: 1.091in / 27.7mm
Length: 7.591in / 192.8mm
Mtg Ear 1 Hole: M8-1.25 Threaded
Mtg Ear 2 Hole: 8.7mm Unthreaded
Mtg Ear 3 Hole: 9.1 Unthreaded
Mounting Ear Center to Center 1: 2.913in / 74mm
Mounting Ear Center to Center 2: 2.913in / 74mm
Mounting Ear Center to Center 3: 2.913in / 74mm
Registry OD: 2.516in / 63.9mm
Replaces these part numbers:
Chrysler: 68201259AA
Fiat: 51890631
Hitachi: S114-943A
