Chrysler Force Marine Outboard Starter 25-35HP

Description

This is a Brand New Starter for Chrsyler and Force

Models:

CHRYSLER Marine-Various Outboard Models

1972 20/25/30/35HP
1973 20/25/30/35HP
1974 20/25/30/35HP
1975 20/25/30/35HP
1976 20/25/30/35HP
1977 20/25/30/35HP
1978 20/25/30/35HP
1979 20/25/30/35HP
1980 20/25/30/35HP
1981 20/25/30/35HP
1982 20/25/30/35HP
1983 20/25/30/35HP
1984 20/25/30/35HP

FORCE Marine

1989 256F 25 HP

1989 257F 25 HP

1990 353F 35 HP
1991 353F 35 HP

1990 356F 35 HP
1991 356F 35 HP

1986 357F 35 HP
1987 357F 35 HP
1988 357F 35 HP
1989 357F 35 HP
1990 357F 35 HP
1991 357F 35 HP
1992 357F 35 HP
1993 357F 35 HP
1994 357F 35 HP
1995 357F 35 HP
1996 357F 35 HP

1990 358F 35 HP
1991 358F 35 HP

Replaces:

API MARINE
MOT4001

ARCO MARINE
5551

CHRYSLER MARINE
46-0955, 51-4955

MERCURY MARINE
50-514955, 50-514955-1

UNITED TECHNOLOGIES
1149540-M030SM, SM11495

OEM(s): Mercury Marine, Johnson Electric
Type: PMDD
Voltage: 12 Volts
Rotation: CCW
Teeth/Splines: 10 Teeth/Splines
Pinion/Splines OD: 38.3mm / 1.508in
DE Housing Number: 0816140
Approximate Weight: 5.1 lbs / 2.32 kg

Notes:
Mounted by 1/4-20 Through Bolts,
3.51"/89.15mm Field Case Length
