Description
Applications:
HONDA Motorcycles NX125 1989 124cc
HONDA Motorcycles NX125 1990 124cc
HONDA Motorcycles NX250 1988 249cc
HONDA Motorcycles NX250 1989 249cc
HONDA Motorcycles NX250 1990 249cc
HONDA Motorcycles NX250 1991 249cc
HONDA Motorcycles NX250 1992 249cc
HONDA Motorcycles NX250 1993 249cc
HONDA Motorcycles NX250-2 1990 249cc
HONDA Motorcycles NX250-2 1991 249cc
HONDA Motorcycles NX250-2 1992 249cc
HONDA Motorcycles NX250-2 1993 249cc
HONDA Motorcycles Off-Road CRF250L 2013 249cc
HONDA Motorcycles Off-Road CRF250L 2014 249cc
HONDA Motorcycles Off-Road CRF250L 2015 249cc
Specifications:
Voltage: 12
CCA: 115
Capacity: (10HR) 8
Weight: 2.60kg / 5.73lbs
Dimensions (in / mm): L: 4.49 (114) W: 2.76 (70) H: 5.04 (128)
Assembly: Figure
Terminal Locations: 2
Terminal: 2, M5x2.5
Screws: 4, M5x7
Allen Wrench: 1, 3x3
Terminal Caps: 2, 11x5.5
Spacer: None
Case Color: Yellow
Replaces these part numbers:
HONDA: 31500-KW3-047, 31500-KW3-037, 31500-KW3-612, 31500-KW3-676, 31500-KW3-613, 31500-KPZ-901, 31500-KW3-671, 31500-KW3-677, 31500-KW3-611
REFERENCE NUMBER: YTX7LBS
