Starter Cub Cadet Lawn Mower 3648 3654 3660 with KAWASAKI 17 23 25 HP Eng

Description

Applications:

This is a Brand New Starter for Cub Cadet and Kawasaki

Models:

Cub Cadet Outdoor Power Equipment

Professional-Grade Mowers
(Gas-Powered)

2002 M48-KW - Kawasaki 23HP
2003 M48-KW - Kawasaki 23HP
2004 M48-KW - Kawasaki 23HP
2005 M48-KW - Kawasaki 23HP
2006 M48-KW - Kawasaki 23HP

2002 M48-KW Tank - Kawasaki 19HP
2003 M48-KW Tank - Kawasaki 19HP
2004 M48-KW Tank - Kawasaki 19HP
2005 M48-KW Tank - Kawasaki 19HP
2006 M48-KW Tank - Kawasaki 19HP

2002 M48-KWS - Kawasaki 17HP

2002 M54-KW Tank - Kawasaki 23HP
2003 M54-KW Tank - Kawasaki 23HP
2004 M54-KW Tank - Kawasaki 23HP
2005 M54-KW Tank - Kawasaki 23HP
2006 M54-KW Tank - Kawasaki 23HP

2004 M60-KW ROPS Tank - Kawasaki 25HP
2005 M60-KW ROPS Tank - Kawasaki 25HP
2006 M60-KW ROPS Tank - Kawasaki 25HP

2002 M60-KW Tank - Kawasaki 25HP
2003 M60-KW Tank - Kawasaki 25HP
2004 M60-KW Tank - Kawasaki 25HP
2005 M60-KW Tank - Kawasaki 25HP
2006 M60-KW Tank - Kawasaki 25HP

2001 3648 - Kawasaki 17HP

2001 3654 - Kawasaki 23HP
2001 3660 - Kawasaki 23HP

2003 H1748 - Kawasaki 17HP
2004 H1748 - Kawasaki 17HP

2003 H1952 - Kawasaki 19HP
2004 H1952 - Kawasaki 19HP

2002 HF1748 - Kawasaki 17HP
2003 HF1748 - Kawasaki 17HP

2002 HF1954 - Kawasaki 19HP
2003 HF1954 - Kawasaki 19HP

2004 HFF1748 - Kawasaki 17HP
2005 HFF1748 - Kawasaki 17HP
2006 HFF1748 - Kawasaki 17HP

2005 RZT50 - Kawasaki 22HP Twin OHV
2006 RZT50 - Kawasaki 22HP Twin OHV

2003 Z-Force 15 - Kawasaki 15HP

2006 Z-Force 60 - Kawasaki 23HP

Kawasaki Outdoor Power Equipment

Engines for Various Models

FH500V
FH531V
FH541V
FH580V
FH601D
FH601V
FH641D
FH641V
FH661V
FH680D
FH680V
FH721D
FH721V
FH770D

Specifications:

OEM: Kawasaki
Type: PMDD
Voltage: 12 Volts
Rotation: CCW
Teeth/Splines: 10 Teeth/Splines
Pinion/Splines OD: 31 mm / 1.220 in
Mounting Hole 1: 9.0 mm ID Unthreaded
Mounting Hole 2: 9.0 mm ID Unthreaded
Approximate Weight: 6.7 lbs / 3.05 kg

Notes:
5.07" / 129 mm Field Housing Length

Replaces these part numbers:

Kawasaki
21163-7001, 21163-7010, 21163-7022, 21163-7029

New Holland
KAW211637001, KAW211637010

Remy Small Motor
RS41057
